SERIES
AXLE
|
CARRY
CAPACITY LBS(KG)
|
AVAILABLE
RATIO
|
AVAILABLE
TRACK RANGE IN(MM)
|
MIN.
RIM (DUAL) SIZE
|
AIR
BRAKE SIZE
|
DIFF.
AND CARR RING GEAR DIA. IN. (MM)
|
PLANET
GEAR RATIO
|
| BD45-60 |
Tandem
50000 (22680) |
9.14
to 22.35 |
72
to 98.5 (1828.8 to 2502.0) |
20 |
16.5
x 7 (419.1 x 177.8) |
13.875
(352.4) |
3529 |
| GCW
155000 (70310) |
| BD50-60 |
Tandem
50000 (22680) |
9.14
to 22.35 |
73.62
to 100.12 (1870.0 to 2543.0) |
20 |
16.5
x 7 (419.1 x 177.8) |
13.875
(352.4) |
3529 |
| GCW
150000 (68040) |
74.12
to 100.62 (1882.6 to 2555.7) |
24 |
20
x 7 (508.0 x 177.8) |
| BD-57000 |
Tandem
60000 (27220) |
8.67
to 21.76 |
90.12
and 100.12 (2289.0 and 2543.0) |
20 |
16.5
x 7 (419.1 x 177.8) |
16.375
(416.0) |
3529 |
| GCW 175000
(79380) |
90.62
and 100.62 (2301.7 and 2555.7) |
24 |
20
x 7 (508.0 x 177.8) |
| D-65200 |
Tandem
60000 (27220) |
8.67
to 21.76 |
80.12
to 100.12 (2035.0 to 2543.0) |
20 |
16.5 x
7 (419.1 x 177.8) |
16.375
(416.0) |
3529 |
| GCW 175000
(79380) |
80.62
to 100.62 (2047.7 to 2555.7) |
24 |
20 x 7
(508.0 x 177.8) |
| BD-71000 |
Tandem
80000 (36290) |
9.00
to 22.60 |
80.62
to 109.88 (2047.7 to 2791.0) |
24 |
20
x 7 (508.0 x 177.8) |
16.375
(416.0) |
3666 |
| GCW 250000
(113400) |
| BD-91000 |
Tandem
100000 (45360) |
9.00
to 22.60 |
86
to 111 (2184.4 to 2819.4) |
24 |
20
x 7 (508.0 x 177.8) |
16.375
(416.0) |
3666 |
| GCW 250000
(113400) |
| BD-101000 |
Tandem
100000 (45360) |
11.46
to 28.77 |
92
to 117 (2336.8 to 2971.8) |
25 |
20
x 7 (508.0 x 177.8) |
16.375
(416.0) |
4666 |
| GCW 300000
(136080) |
| BD-121000 |
Tandem
120000 (54430) |
12.31
to 15.27 |
106
(2692.4) |
25 |
20
x 7 (508.0 x 177.8) |
18.50
(470.0) |
4666 |
| GCW
500000 (226800) |
| Note:
Ratings may vary with application. Approval for all applications must
be obtained. |
